12-bit, 5MS/s SAR ADC IP Core for Ultra-Low Power Precision Applications: T2M Unveils New IP

02 Jun, 2025

T2MIP, The world’s largest independent global semiconductor IP cores provider, proudly announces the launch of its latest high-performance ADC IP core: a 12-bit SAR ADC capable of achieving conversion speeds up to 5MS/s with outstanding dynamic performance and exceptional power efficiency.


Engineered for integration into next-generation microcontrollers, industrial instrumentation, and broadband wireless systems, T2M’s new 12-bit, 5MS/s SAR ADC IP Core combines flexible configuration modes, a compact footprint, and an ultra-wide power supply range to deliver unmatched versatility for system designers.

Key Features:
  • 12-bit Resolution with up to 5MS/s Conversion Rate
  • High Dynamic Performance: SINAD of 70dB, THD of 72dB, and ENOB of 11.3 bits
  • Multiple Input Modes: Supports both single-ended and differential configurations with up to 4 input channels
  • Zero DC Power with scalable consumption tied to clock frequency
  • Selectable Resolution: Operates in 8, 10, or 12-bit modes
  • Multiple Conversion Modes: Continuous and single conversion modes supported
  • Extended Sampling & Power Modes: Includes low-power and low-noise modes for tailored performance
  • Flexible Reference Options: External and optional internal reference support
  • Ultra-Low Voltage Operation: Analog supply from 3.3V to 1.8V; Digital supply at 1.1V
  • Advanced Functions: Self-calibration, optional hardware averaging, window watchdog
This IP core is ideal for SoC and ASIC designs that demand both precision and energy efficiency. With its configurability and compact implementation, it addresses a broad range of application needs while simplifying integration and minimizing system power budgets.

The IP  core is available for immediate licensing. For further details, visit t-2-m.com or contact T2M at [email protected]
